Specification:

Size: L2230mm*W990-1050mm*H520-760mm

Technical Data:

Vertical Travel: 200mm

Back Rest Upward: 0-75 °

Foot Rest Upward: 0-45 °

Tilt Head ward and Foot ward  Respectively: ±10 °

Using Instruction and Notes:

1. Safe working load-maximum 250KG

2. All controlled parts must be operated by medical personnel.

3.When need to remove head and foot boards to meet medical requirement, medical personnel should

stand well, open the clamp, clutch both side ends of head and foot boards and pull it vertically.

4. Patient and family members are not allowed to use any parts of bed to take exercise, get well exercise

or personal injury or equipment damage could occur.

5. Before moving the bed indoor, need to release the brake. When reach the desired position. set the brake

it's not allowed to move the bed in force on uneven floor.

6. Do not use chlorine disinfectant to disinfect hospital bed

7. If there are some problems please call the company for assistance. We will offer maintenance service

Out of guarantee will charge on the circumstance
